TD20 Series VFD Function Parameters
-82-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
Setting range: -300.0%–300.0%
(the rated current of the motor)
P17.09
Output torque
Display the current output torque of the VFD.
Range: -250.0–250.0%
●
P17.10
The motor
frequency
evaluation
Evaluate the motor rotor frequency on open loop vector
Range: 0.00– P00.03
●
P17.11
DC bus
voltage
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
●
P17.12
Switch input
terminals state
Display current Switch input terminals state of the VFD
Range: 0000–00FF
●
P17.13
Switch output
terminals state
Display current Switch output terminals state of the VFD
Range: 0000–000F
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the VFD.
Range: 0.00Hz–P00.03
●
P17.15
Torque
reference
Display the torque reference, the percentage to the
current rated torque of the motor.
Setting range: -300.0%–300.0%
(the rated current of the motor)
●
P17.16
Linear speed
Display the current linear speed of the VFD.
Range: 0–65535
●
P17.17
Reserved
●
P17.18
Counting
value
Display the current counting number of the VFD.
Range: 0–65535
●
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00–10.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00–10.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00–10.00V
●
