TD20 Series VFD Function Parameters
-83-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.00–50.00kHz
●
P17.23
PID reference
value
Display PID reference value
Range: -100.0–100.0%
●
P17.24
PID feedback
value
Display PID feedback value
Range: -100.0–100.0%
●
P17.25
Power factor
of the motor
Display the current power factor of the motor.
Range: -1.00–1.00
●
P17.26
Current
running time
Display the current running time of the VFD.
Range: 0–65535min
●
P17.27
Simple PLC
and the
current stage
of the
multi-step
speed
Display simple PLC and the current stage of the
multi-step speed
Range: 0–15
●
P17.28
ASR controller
output
The percentage of the rated torque of the relative motor,
display ASR controller output
Range: -300.0%–300.0% (the rated motor current)
●
P17.29
Reserved
●
P17.30
Reserved
●
P17.31
Reserved
●
P17.32
Magnetic flux
linkage
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
●
P17.33
Exciting
current
reference
Display the exciting current reference in the vector
control mode.
Range: -3000.0–3000.0A
●
P17.34
Torque current
reference
Display the torque current reference in the vector control
mode.
Range: -3000.0–3000.0A
●
