21
SPECIFICATIONS
Amplifier Section
Output Power (Front) :
F.T.C. Rating :
260 Watts total.
130 watts RMS per channel minimum, both channels
driven into 8 ohms from 20 Hz to 20 kHz with no more
than 0.9% total harmonic distortion(U.S.A./Canada)
Delay Time :
DOLBY PRO LOGIC : 15 ~ 30mS
HALL/THEATER : 15 ~ 50mS
Input Sensitivity/Impedance :
PHONO : 2.5 mV/47 k ohms
LINE : 220 mV/47 k ohms
Frequency Response :
PHONO : 20 Hz ~ 20kHz, ±1 dB
LINE : 10 Hz ~ 60 kHz, +1/ -3 dB
Signal-to-Noise Ratio :
PHONO : 65 dB (IHF-A)
LINE : 90 dB (IHF-A)
Tone Control :
BASS : ±10 dB at 100 Hz
TREBLE : ±10 dB at 10 kHz
FM Tuner Section
Tuning Range :
87.5 MHz ~ 108.0 MHz (100 kHz steps)
(U.S.A./Canada)
Usable Sensitivity (IHF) :
Mono : 15 dBf (U.S.A./Canada)
50 dB Quieting Sensitivity :
Mono : 23 dBf (U.S.A./Canada)
Stereo : 40 dBf (U.S.A./Canada)
Capture Ratio :
2.0 dB (U.S.A./Canada)
Image Rejection Ratio :
40 dB (U.S.A./Canada)
AM Suppression Ratio : 40 dB
Total Harmonic Distortion (1 kHz) :
Mono : 0.4%
Stereo : 0.5%
Frequency Response : 30 Hz ~ 15 kHz, +1/ -1.5 dB
Stereo Separation (1 kHz) : 40 dB
Signal-to-Noise Ratio :
Mono : 65 dB
Stereo : 60 dB
AM Tuner Section
Tuning Range :
530 kHz - 1,720 kHz (10 kHz steps)
(U.S.A./Canada)
Usable Sensitivity : 55 dB/m
Total Harmonic Distortion : 0.8% at 85 dB/m
Signal-to-Noise Ratio: 45 dB at 85 dB/m
Video Section
Input Sensitivity /Impedance : 1.0 Vp-p/75 ohms
Output Level /Impedance : 1.0 Vp-p/75 ohms
General
Power Requirements :
120 V AC, 60 Hz (U.S.A./Canada)
Power Consumption :
3.0 A (U.S.A./Canada)
AC Outlets :
Switched x 2, Total 100 W max. (1 A max.)
(U.S.A./Canada)
Dimensions (W x H x D) : 435 x 165 x 345 mm
Weight (net) : 20 lbs
Standard Accessories :
AM Loop Antenna x 1
FM “T” Type Antenna x 1
Remote Control Unit x 1
Owner’s manual x 1
AAA Batteries x 2
* LINE means CD, VIDEO 1, VIDEO 2, DVD/VIDEO 3 and
TAPE 1.
Improvements may result in specifications and
features changing without notice.
Illustrations may differ slightly from production
models.
