CONNECTIONS
System Connections
CAUTION : Do not plug the power cord of any
component into AC outlets and do not turn their POWER
switches on until all connections have been performed.
: Audio signal
: Video signal
Refer to “Antenna Connections” on pages 6~7.
TV Monitor
Turntable
Tape Deck
CD Player
LINE OUT
LINE IN
AC Outlets:
Two switched, Total 100W.
VIDEO OUT
AUDIO OUT
VIDEO OUT
VIDEO IN
AUDIO OUT AUDIO IN
REAR SURROUND
SPEAKERS
MAIN SPEAKERS
Audio connection cords
DVD/VIDEO 3
VIDEO 1
