Tecma X-light - Page 123

Operation/installation/service manual MACERATOR TOILETS
Manuale di utilizzo / installazione / manutenzione TOILET MACERATRICI
X-light / Privilege / Evolution / Breeze / E-Breeze / Silence Plus / Elegance / Saninautico / Prestige
123
www.thetfordmarine.com / TECMA SRL – Via Flaminia / Loc Castel delle Formiche/ 05030 Otricoli (TR) / Italy
Manual rev 25.2014 ©TECMA SRL
Reference
TECMA PART NUMBER
Voltage
Description
1
T-PF.P01A
12 volts
MACERATOR PUMP / POMPA MACERATRICE
T-PF.P01B
24 volts
MACERATOR PUMP/ POMPA MACERATRICE
T-PF.P87
110 volts
MACERATOR PUMP/ POMPA MACERATRICE
T-PF.P64
230 volts
MACERATOR PUMP/ POMPA MACERATRICE
2
T-PF.P29/A
DISCHARGE HOSE WITH ONE WAY VALVE/TUBO SCARICO
T- PF.P86
ONE WAY VALVE/ VALVOLA DI NON RITORNO
T- PF.P13/A
STANDARD SIPHONE HOSE / TUBO SIFONE
T-PF.P50
COMPLETE RUBBER KIT ( T-PF.P29/A + T-PF.P13/AT-PF.P86)/KIT COMPLETO
3*
*not for X-Light
T-PF.P03/B
INLET NOZZLE WHITE / UGELLO DI IMMISSIONE BIANCO
T.PF.P03/P
INLET NOZZLE PERGAMON (BONE)
T.PF.P03/N
INLET NOZZLE BLACK
T-PF.P03B/B
INLET NOZZLE WHITE WITH BIDET SHOWER FUNCTION
T.PF.P03B/P
INLET NOZZLE PERGAMON WITH BIDET SHOWER FUNCTION
T.PF.P03B/N
INLET NOZZLE BLACK WITH BIDET SHOWER FUNCTION
4
FOR SEAT AND COVER SPARES SEE NEXT PAGE
5
T-PF.P11/B
ALL IN ONE 1 BUTTON WALL SWITCH / CENTRALINA 1 PULSANTE
T-PF.P11
ALL IN ONE 2 BUTTON WALL SWITCH/ CENTRALINA 1 PULSANTE
T- PF.P11M1
MULTIFRAME 1 BUTTON CONTROL PANEL
T- PF.P11M2
MULTIFRAME 2 BUTTONS CONTROL PANEL
T- PF.P11A1
ARGENT 1 BUTTON CONTROL PANEL
T- PF.P11A2
ARGENT 2 BUTTONS CONTROL PANEL
T- PF.P11T1
TOUCH 1 BUTTON CONTROL PANEL
T- PF.P11T2
TOUCH 2 BUTTONS CONTROL PANEL
T-PF.P11T/T
PREMIUM CONTROL PANEL KIT (WALL SWITCH + CONTROLLER + STA)
T-PF.P11T/T-TOUCH
PREMIUM TOUCH CTRL PANEL KIT(TOUCH WALL SWITCH + CONTROLLER + STA+CABLE)
T-PF.PE20
STA – SINGLE TOILET ADAPTER
6
T-PF.P14/I
12 volts
INVENSYS SOLENOID 12 v / ELETTROVALVOLA
T-PF.P15/I
24 volts
INVENSYS SOLENOID 24 v / ELETTROVALVOLA
T-PF.P12/I
230 volts
INVENSYS SOLENOID 230 v / ELETTROVALVOLA
T-PF.P47/I
110 volts
INVENSYS SOLENOID 110 v / ELETTROVALVOLA
6a
T -PF.P14
T-PF.P15
T-PF.P12
T-PF.P47
12 volts
CEME SOLENOID 12 v / ELETTROVALVOLA
T-PF.P15
24 volts
CEME SOLENOID 24 v / ELETTROVALVOLA
T-PF.P12
230 volts
CEME SOLENOID 230 v / ELETTROVALVOLA
T-PF.P47
110 volts
CEME SOLENOID 110 v / ELETTROVALVOLA
T -PF.P14/B
T-PF.P15
T-PF.P12
T-PF.P47
12 volts
PILOT OPERATED SOLENOID BRASS 12v / ELETTROVALVOLA SERVOASSISTITA
T-PF.P15/B
24 volts
PILOT OPERATED SOLENOID BRASS 24v / ELETTROVALVOLA SERVOASSISTITA
T-PF.P12/B
230 volts
PILOT OPERATED SOLENOID BRASS 230v / ELETTROVALVOLA SERVOASSISTITA
7
T-PF.P27
12 volts
INLET PUMP / POMPA DI IMMISSIONE
T-PF.P28
24 volts
INLET PUMP/ POMPA DI IMMISSIONE
Prestige specific
T-PF.P56
PRESTIGE GENERAL REPARATION KIT
T-PF.P49
12/24 V
PRESTIGE PROGRAMMER / CENTRALINA PRESTIGE
T-PF.P26
230 V
PRESTIGE PROGRAMMER
T-PF.P54
PRESTIGE RUBBER KIT/ KIT MANICOTTI PRESTIGE
