Tecma X-light - Einzel- und Mehrfachanlage; Impianto Singolo Multiplo

Operation/installation/service manual MACERATOR TOILETS
Manuale di utilizzo / installazione / manutenzione TOILET MACERATRICI
X-light / Privilege / Evolution / Breeze / E-Breeze / Silence Plus / Elegance / Saninautico / Prestige
129
www.thetfordmarine.com / TECMA SRL – Via Flaminia / Loc Castel delle Formiche/ 05030 Otricoli (TR) / Italy
Manual rev 25.2014 ©TECMA SRL
8.2 MULTIPLE SINGLE SYSTEM / IMPIANTO SINGOLO MULTIPLO
Y SELECTION VALVE
HOLDING TANK with
TECMA sensor
HOLDING TANK DISCHARGE PUMP
BLACK WATER OUTLET
- HULL
BLACK WATER OUTLET
- DECK
6
7
8
9
10
RAW WATER INTAKE
– ball valve seacock
RAW WATER STRAINER
TECMA RAW WATER PUMP
TECMA VENTILATION VALVE
– siphon break
TECMA MACERATOR TOILET
1
2
3
4
5
