PROVASET T3LPF REV.20210610
23
Electronic pressure regulator.
The pressure is automatically adjusted to the programmed nominal pressure, cor-
rected by the
RP%-
sible, with up and down ramps.
The adjusted pressure is read by a dedicated transducer and is visible in a menu page
on the screen, to check the output pressure before starting a test.
V1
Internal valve, normally closed, open only during testing for the emission of air at the
TEST output to the component being tested.
TEST
Output connection to the test circuit, for pipe Ø 8 x 6 mm.
TP
Connection for reading the internal test pressure, on the TEST output.
If the test pressure is read directly on the component being tested, the bypass output
must be closed.
Quick coupling with Staubli RBE03 type check valve on the front panel for the connec-
tion of a leak master.
V2
Internal valve, normally closed, open only to relieve the pressure in the component
being tested.
Pressure transducer for measurement of the relative test pressure, to be connected
to the TEST output (bypass connection) or directly to the component being tested,
with a separate tube.
