PROVASET T3LPF REV.20210610
26
pressure reading is taken directly on the tested component and is independent from
-
If the component being tested has only one access point, the two tubes must be
tested.
Sealing cap
H Test pressure reading
I Connection tube to the tested component
J Component being tested
K
CD
E
G
H
F
TEST
IK
p
J
The pressure on the output port G is equal to the test pressure plus the pressure drop
The output pressure at port G is regulated automatically by an internal proportioning
valve that works properly at pressures higher than about 50 mbar.
