PROVASET T3LPF REV.20210610
27
output tube; if the test pressure is also small, then the total output pressure
required at port G may become less than 50 mbar and it will not be regulated
correctly.
To avoid this condition, insert a restriction on the output tube, so that the air
with a small internal diameter, for example, a Ø 4 x 2.5 mm tube instead of the
standard Ø 8 x 6 mm.
In any case, the pressure reading of the test pressure at port H, taken from the
the output tube.
Regulated pressure display
The pressure regulated by the internal proportioning valve is shown in an infor-
mation page of the basic menu, accessible with the left and right arrow keys.
For tests at low pressure, less than 50 mbar, it is strongly recommended to ena-
