PROVASET T3LPF REV.20210610
48
The test pressure must also be greater than the pressure drop limit in
the time
AT
NO: tare not executed; YES: automatic tare enabled.
QHD
For models T3LPFxxxP05 and T3LPFxxxP2 only, the pressure reading resolution is
pressures can be high or low resolution.
Changing the QHD parameter changes the format of the Q+ and Q- (leak limits) pa-
rameters, which must be reprogrammed, and the format of the pressure drop dis-
played in measurement phase T3.
Measure test phase
T3
Time of measurement of the pressure drop of the test circuit at the TEST output,
TEST output in time
programming range:
resolution 0.1 Pa: +/- 6000.0 Pa (+/- 60.000 mbar);
Resolution 1 mbar +/- 60000 Pa (+/- 600.00 mbar).
An increase in pressure is an abnormal condition; a minimum pressure drop may be
required in some applications.
limit
scc/m or scc/h.
circuit at the TEST output in time
programming range as for the limit, but only
with negative sign (leak with pressure drop).
The leak limit
, with negative sign, must always be lower than the pressure limit .
Examples:
= 50 Pa, = -10 Pa; = -5 Pa, = -10 Pa.
If the
limit is programmed below the limit, the limit value is automatically
corrected.
The test has
PASSED only if the pressure delta in time remains within the limits
and
.
