PROVASET T3LPF REV.20210610
49
limit
in scc/min or scc/h.
End mode of measurement phase
.
The measurement phase ends when the time
= TIME) expires or when the
leak limit Q
This mode is used to save time and switch immediately to a new test before the time
runs out.
Used to calculate the leak rate Q equivalent to the pressure drop in time
.
ideally corresponds to the test volume on the TEST out-
put (volume of the component being tested + volume of pipes + internal volume of
the instrument).
a leak master or a
5.6.5 Leak test: leak rate Q
parameter, programmed in the active test
leak rate Q, expressed in scc/m or scc/h.
The leak rate Q is calculated using the following formula which derives from the gen-
eral laws of (ideal) gases and which can also be applied to air, when it is close to am-
bient conditions:
T3 = 5 s =5/60 minutes, air temperature= 273 °K:
Q= (0.27 * (- 0.35) * 31.2 * 60) / (5 * 273) = - 0.13 scc/m
