PROVASET T3LPF REV.20210610
50
5.6.6 Leak test: PASSED/FAILED result messages
5.6.6.1 PASSED result messages
PASSED
measured during the time T3, does not exceed the limits Q+ (pressure increase) and
Q- (pressure drop) programmed in the test program.
5.6.6.2 FAILED result messages
Leak or burst test: after phase T1, the pressure dropped below the PR%MIN limit
compared to the programmed PR test pressure.
The test pressure exceeded the PR%MAX limit with respect to the programmed test
pressure PR.
The test pressure has exceeded the maximum full-scale pressure by at least 10%.
programmed limit Q-.
the programmed positive Q+ limit.
the programmed negative Q+ limit.
Out of range pressure result, MAX PRESSURE ERROR.
Out of range pressure result, MIN PRESSURE ERROR.
5.7 Volume + leak test (sealed parts): test cycle and parameters
A method to control or measure the volume of air, that is supplied to the test circuit,
is necessary for the following types of tests:
• volume test: control of the volume of the tested components;
