PROVASET T3LPF REV.20210610
57
5.8.3 Printing parameters
STM
Print mask (template), range 0:100.
The printing masks must be stored on the printer with external means (Tecna Srl can
provide a program for managing the printing masks for certain printer models).
The
STM parameter is sent to the printer before the data is printed, to choose the
format and presentation of the data to be printed, according to the tested product
STS
Printing mode according to the result of the test.
No: print only with result PASSED;
YES: print at the end of each test, with any result.
STN
Label printer: number of labels to be printed.
Field 0: 15;
STN = 0, printing disabled; typical value STN = 1.
5.8.4 Discharge phase parameters
At the end of a test, the pressure in the test circuit is automatically discharged only if
the discharge function is programmed in the corresponding parameters of the test
program.
Pressure discharge mode at the end of the test.
NO: the discharge is disabled.
: the discharge remains active until the next test.
: the discharge is only activated with a failed result.
PASSED: the discharge is only activated with a passed result.
TIME: the discharge is activated for the set time.
PRESSURE: the discharge is activated until the pressure inside the component being
tested falls below the set pressure.
During the phase of discharging pressure in the test circuit.
With
=PRESSURE, the pressure must be discharged within the time .
With
=TIME, the internal valves are open in discharge at the end of the test for
the time
.
Field 0.0 : 3600.0 s.
