PROVASET T3LPF REV.20210610
64
6.5 Unit: digital outputs
A maximum of 16 outputs are available; the number of outputs actually available
depends on the expansion boards installed, I/OB type (8 inputs + 8 outputs), with a
maximum of two boards.
Available outputs are programmable, unavailable outputs are obscured.
: free outputs for PLC signals
alarm.
Output signal on an expansion board
• not assigned
• test in progress
• : test not in progress
• result
PASSED
• result
• output = 0 the programs are enabled; output = 1 the
products are enabled
• : result
PASSED previous test
• : result
previous test
• acoustic signal Failed/Alarm
• acoustic signal Failed/Alarm
• pre-adjustment with external valve
• External valve for vacuum module (MAV)
• external valve (volume control)
• alarm signal (reversed, 0=alarm)
• automation control 1
• automation control 2
• Automation: marker command
• External discharge valve control
• output for external devices command (option)
• output with result
PASSED in step n of a sequence
• output with result
in step n of a sequence
• Square wave signal, period 100 ms.
Manual activation of digital outputs.
Selecting the test function opens a page that displays the status of the outputs, as in
the base menu, but in this page the outputs can also be activated manually by press-
ing the corresponding keys.
