WARNING ! Please verify that activating
digital outputs does not harmany people
and/or objet !
TEST OUTPUTS
Risk of moving parts and parts under pressure.
If the digital outputs are used to control external components (valves, cylinders,
etc.), manual activation can be dangerous for the operator and the equipment.
Manual activation of the internal valves
Selecting the test function it opens a page through which it is possible to activate /
deactivate the individual internal valves of the instrument. Each valve corresponds to
a button, but, depending on the model of the instrument, not all buttons are valid.
1
23 4 567
8
ATTENZIONE !! premendo sui bottoni sottostanti
si attiverà la valvola interna corrispondente.
Verificare collegamenti esterni
prima di procedere!
TEST valvole circuito interno
The manual activation of the valves can be dangerous for the user
and for the instrument.
6.6 Unit: automations (Option)
Automation 1: maximum delay of limit switch FC1-Automation 1; Range 0 : 3600.0 s;
0=not used, function disabled.
Automation 1: maximum delay of limit switch FC2-Automation 1; Range 0: 3600.0 s;
0=not used, function disabled.
