PROVASET T3LPF REV.20210610
77
the set pressure in the program. Once the required value has been entered, the in-
strument will proceed with the second step.
VOLUMETRIC COEFFICIENT
PROG n°001: VALVE_A
Please insert the leak master
Master Leak scc/m
0.000
START
TEST
VOLUMETRIC COEFFICIENT
CV: Volumetric coefficient
Yes No
PROG n°001: VALVE_A
1.000 L
0.0 Pa
P. leak without leakmaster
Get new values?
-
tained or repeat the entire process.
The value of the leak without the leak master will be saved in the parameter P. leak
without leakmaster (step 1 of the procedure). This parameter is reset if the CV is
changed manually by the user in the test program.
-
plings that can be inserted in the STAUBLI RB03 type sealed sockets on the front
panel.
PR test
pressure programmed in the test program.
7.2 Utility: Autotest cycle
It is possible to activate the autotest cycle from the UTILITY menu and then AUTO-
TEST CYCLE.
This cycle is used to repeat the active program or product.
T3L will proceed with a new test within the time indicated in DELAY (s).
Pay attention!
