TECNOEKA Srl ______________________________________________________________ use and instruction manual
page 6 __________________________________________________________________________________________
Connection to the water mains (MODD. EKF 423 U) - The appliance must be fed with softened
drinking water, with hardness from 0.5°F to 3°F (it is obligatory to use a softener to reduce the
formation of lime inside the cooking chamber) and pressure in the range from 100 to 200 kPa
(1.0 - 2.0 bar).
Connection to the water mains should be made through the threaded 3/4" solenoid-valve on
the rear (on the bottom) of the appliance, fitting in between a mechanical filter and an on/off
tap (before you connect the filter, allow a certain quantity of water to flow out in order to drain
any waste from the pipe).
Connection of power cable - The terminal board is on the rear panel of the appliance. Open the
terminal board cover by obtaining leverage with a screwdriver on the two side fins. Loosen the
cable gripper screw and allow the cable to pass through it. Arrange the conductors so that the
earth conductor is the last to detach from its terminal if the cable goes into a state of faulty
traction. Connect the phase conductor to the terminal marked with the letter "L", the neutral
conductor to the terminal marked with the letter "N" and the earth conductor to the terminal
marked with the symbol . Tighten the ring-nut of the cable gripper and close the terminal
board cover. The appliance must be connected to an equipotential system whose efficiency
must first be checked according to current legal regulations. This connection must be made
between different appliances by using the appropriate terminal marked with the symbol . The
equipotential conductor must have a minimum diameter of 2,5 mm
2
The equipotential terminal
is at the rear of the appliance.
Safety thermal breaker - The appliance has safety thermal breaker. It protects against excessive
dangerous over-temperatures which could be accidentally generated inside the appliance. If the
device is tripped, it interrupts electrical power to the appliance and thus prevents it from
operating.
5. Use instructions (for the user)
This appliance is not intended for use by persons (including children) with reduced phycal,
sensory or mental capabilities, or lack of experience and knowledge. Unless they have
beengiven supervision or instruction concerning use of appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
For first use, we advise you to let the appliance to run load-free at maximum temperature for
about one hour. In this way, any unpleasant smells due to thermal insulation and residual work
grease are eliminated.
This appliance must be used solely for the purpose for which it was expressly designed, i.e.
cooking foods in the oven. Any other use is considered unsuitable.
The appliance can be used: for all oven cooking of deserts, pizzas, meat, fish, vegetables, as
well as for gratinating, and for re-conditioning cooled and frozen foods.
When placing food in the cooking compartment, leave a space of at least 40 mm between pans
in order not to over-obstruct air circulation.
Do not use pans with higher than necessary edges: edges are barriers which prevent the
circulation of hot air.
Warm up the oven before every cooking operation to obtain maximum uniformity.
Do not salt foods in the cooking compartment.
