3.4 - When you press the coffee switch (2), the pump goes on but
no coffee comes out of the spout (11) and water comes out of the
hot water pipe (9) (see fig. 19 and 20).
fig.19 fig.20
Possible reasons:
The solenoid valve (e1) may be dirty or faulty, and therefore stays locked in
its open position (see fig. 20).
Operations:
Clean or replace the solenoid valve (e1) as shown on figures 21 and 22.
1 – Unscrew the nut.
2 - Take out the spool (see fig.21)
fig.21 fig.22
3 – Unscrew the steel sleeve (see fig.22).
4 – Take out the inside cylinder to see whether it needs to
be cleaned, for example from calcium residue.
5 – Unscrew the brass base in order to replace the whole
solenoid valve if necessary.
6 – Reassemble the whole unit carrying out the operations in
reverse order.
