TECO T-Verter E2-2P5-M1F User Manual

61
TECO recommends using UL-listed copper wires (rated at 75°C) and closed-loop lugs or CSA-certified
ring lugs sized for the selected wire gauge to maintain proper clearances when wiring the drive. Use the
correct crimp tool to install connectors per manufacturer recommendation. Table lists a suitable
closed-loop lugs manufactured by NICHIFU Corporation.
Wire Gauge
mm
2
(AWG)
Terminal
Screw
R-Type Connectors
(Lugs) Part Numbers
Tightening Torque
kgf.cm (in.lbs)
Insulation
CAP
Crimping Tool
M3.5 R1.25-3.5 8.2 to 10 (7.1 to 8.7) TIC 0.5 NH 82
0.75 (18)
M4 R1.25-4 12.2 to 14 (10.4 to 12.1) TIC 0.5 NH 82
M3.5 R1.25-3.5 8.2 to 10 (7.1 to 8.7) TIC 1.25 NH 82
1.25 (16)
M4 R1.25-4 12.2 to 14 (10.4 to 12.1) TIC 1.25 NH 82
M3.5 R2-3.5 8.2 to 10 (7.1 to 8.7) TIC 2 NH 82
M4 R2-4 12.2 to 14 (10.4 to 12.1) TIC 2 NH 82
M5 R2-5 22.1 to 24 (17.7 to 20.8) TIC 2 NH 82
2 (14)
M6 R2-6 25.5 to 30.0 (22.1 to 26.0) TIC 2 NH 82
M4 R5.5-4 12.2 to 14 (10.4 to 12.1) TIC 3.5/5.5 NH 82
M5 R5.5-5 20.4 to 24 (17.7 to 20.8) TIC 3.5/5.5 NH 82
M6 R5.5-6 25.5 to 30.0 (22.1 to 26.0) TIC 3.5/5.5 NH 82
3.5/5.5 (12/10)
M8 R5.5-8 61.2 to 66.0 (53.0 to 57.2) TIC 3.5/5.5 NH 82
M4 R8-4 12.2 to 14 (10.4 to 12.1) TIC 8 NOP 60
M5 R8-5 20.4 to 24 (17.7 to 20.8) TIC 8 NOP 60
M6 R8-6 25.5 to 30.0 (22.1 to 26.0) TIC 8 NOP 60
8 (8)
M8 R8-8 61.2 to 66.0 (53.0 to 57.2) TIC 8 NOP 60
M4 R14-4 12.2 to 14 (10.4 to 12.1) TIC 14 NOP 60/ 150
M5 R14-5 20.4 to 24 (17.7 to 20.8) TIC 14 NOP 60/ 150
M6 R14-6 25.5 to 30.0 (22.1 to 26.0) TIC 14 NOP 60/ 150
14 (6)
M8 R14-8 61.2 to 66.0 (53.0 to 57.2) TIC 14 NOP 60/ 150
M6 R22-6 25.5 to 30.0 (22.1 to 26.0) TIC 22 NOP 60/ 150
22 (4)
M8 R22-8 61.2 to 66.0 (53.0 to 57.2) TIC 22 NOP 60/ 150
M6 R38-6 25.5 to 30.0 (22.1 to 26.0) TIC 38 NOP 60/ 150
30/38 (3 / 2)
M8 R38-8 61.2 to 66.0 (53.0 to 57.2) TIC 38 NOP 60/ 150
M8 R60-8 61.2 to 66.0 (53.0 to 57.2) TIC 60 NOP 60/ 150
50 / 60 (1 / 1/ 0)
M10 R60-10 102 to 120 (88.5 to 104) TIC 60 NOP 150
M8 R70-8 61.2 to 66.0 (53.0 to 57.2) TIC 60 NOP 150
70 (2/0)
M10 R70-10 102 to 120 (88.5 to 104) TIC 60 NOP 150
M10 R80-10 102 to 120 (88.5 to 104) TIC 80 NOP 150
80 (3/0)
M16 R80-16 255 to 280 (221 to 243) TIC 80 NOP 150
M10 R100-10 102 to 120 (88.5 to 104) TIC 100 NOP 150
M12 R100-12 143 to 157 (124 to 136) TIC 100 NOP 150
100 (4/0)
M16 R80-16 255 to 280 (221 to 243) TIC 80 NOP 150
