DMX-512 Connections
The DMX-512 is widely used in intelligent lighting control
with a maximum of 512 channels.
Temperature reduces signal error and avoids signal trans-
mission problems and interference. It is always advisable to
connect a DMX terminal.
(Resistance 120 ohm 1/4W) between pin2 (DMX-) and pin3
(DMX+) of the last xture
1CH Channel mode
RAZOR CUBE - LED MOVING HEAD MATRIX LIGHT
ENGLISH VERSION
