Betriebsanleitung/Operating manual
E3905 / P3394
40 BD_BE 763 b www.tecsis.de
11 Technical specifications
Measuring ranges:
Display range: max. -1999...9999 digit, depending on connected sensor
Resolution: depending on connected sensor
Pressure units: mbar, bar, kPa, MPa, mmHg, PSI, selectable depending on
connected sensor
Accuracy: (type.) ±0,2%FS opt .:0,1% (FASt and P.dET: ±0.5%FS)
Temperature effect ±0,4%FS (0-50°C)
Measuring rate: slow: 4 meas./sec (ConF-Rate = Slow)
fast: >100 meas./sec (ConF-Rate = FASt and P.dEt)
Nominal temperature: 20°C
Sensor: All sensors of the Manoport-series without re-calibration can be
connected
Pressure connection G1/2
Material of wetted parts stainless steel
Overpressure safety see data sheet „Manoport“
Electr. Connection: Mini-DIN-Socket with locking mechanism
The sensor will automatically be detected, the measurement range
settings are set referring to sensor data
Additional Functions:
Power-Off-Function: Device will be automatically switched off if no key is pressed / no
interface communication takes place for the time of the power-off
delay. The power-off delay can be set to values between 1 and 120
min.; it can be completely deactivated.
Min/Max-Alarm: The measuring value is constantly monitored for the min. and max.
rails set.
Alarming is done by integrated horn, display and interface
Real time clock: Integrated clock with date and year
Logger: 2 Functions: individual value logger („Func–Stor“) and
cyclic logger („Func–CYCL“)
Memory: Store: 99 data sets; CYCL: 1800 data sets or resp. 5400 (1 channel)
Cycle time CYCL: 1...3600 seconds
Display: 2 four digit LCDs (12.4mm high and 7 mm high) for measuring values
and for min/ max memories, hold function, etc. as well as additional
functional arrows.
Pushbuttons: 6 membrane keys
Interface: Serial interface (3.5mm jack) can be connected to RS232 interface of
a PC via electrically isolated interface adapter (see accessories).
Power supply: 9V battery, type: IEC 6F22 (included in scope of supply)
as well as additional d.c. connector (diameter of internal pin 1.9 mm)
for external 10.5-12V direct voltage supply.
