Betriebsanleitung/Operating manual
E3905 / P3394
44 BD_BE 763 b www.tecsis.de
Refilling
Proceed as follows to refill and proceed in the given sequence.
1.) Open one of the pressure connections on the manifold
of the pump (only in
unpressurised conditions)
2.) Turn the pump spindle clockwise until the pressure medium becomes visible in the opened
pressure connection.
3.) Now turn the pump spindle anticlockwise to the stop and observe the liquid level in the
pressure connection.
The system must always be filled with as much liquid as to ensure a constant liquid level in
the pressure connection.
