TECSYSTEM NT538 - MODBUS MAPPING TABLE: CONFIGURATION; MODBUS MAPPING TABLE: ADDRESS CONFIGURATION REGISTERS; MODBUS MAPPING TABLE: TEMPERATURE FAN SETTING REGISTERS

23
NT538
17 00 Address Modbus address 1÷255 R
18
00
Bdr
Modbus baud
rate
0=2400
1=4800
2=9600
3=19200
4=38400
R
19 00 Parity Modbus parity bit 0=No
1=Even
2=Odd
R
20 00 FREE See Note R
TEMPERATURE FANs:
Address
LO
(10)
Data HI Data LO Note 1 Note 2
R: read
W:write
RW: read/write
21 2’compl. sign Fan_1 ON
1°C ÷ 240°C
1°C ÷ 200°C (*)
RW
22 2’compl. sign Fan_1 OFF
1° to÷ 240°
1°C ÷ 200°C (*)
RW
23 2’compl. sign Fan_2 ON
1° to÷ 240°
1°C ÷ 200°C (*)
RW
24 2’compl. sign Fan_2 OFF
1° to÷ 240°
1°C ÷ 200°C(*)
RW
(*) for version –40°C ÷ +200°C
TEMPERATURES channels 1÷8:
Address
LO
(10)
Data HI Data LO Note 1 Note 2
R: read
W:write
RW: read/write
25 2’compl. sign 2’compl. Ch1 temper.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
26 2’compl. sign 2’compl. Ch1 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
27 2’compl. sign
2’compl. Ch1 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
(AL) RW
28 2’compl. sign
2’compl. Ch1 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
(TRP) RW
29 2’compl. sign 2’compl. Ch2 temper.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
30 2’compl. sign 2’compl. Ch2 max temperat.
0°C÷ 240°C
0°C÷200°C (*)
R
31 2’compl. sign
2’compl. Ch2 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL) RW
32 2’compl. sign
2’compl. Ch2 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
33 2’compl. sign 2’compl. Ch3 temper.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
34 2’compl. sign 2’compl. Ch3 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
