TECSYSTEM NT538 - MODBUS MAPPING TABLE: CH3-CH8; MODBUS MAPPING TABLE: TEMP SETTINGS CH3-CH4; MODBUS MAPPING TABLE: TEMP SETTINGS CH5-CH6; MODBUS MAPPING TABLE: TEMP SETTINGS CH7-CH8

24
NT538
35 2’compl. sign
2’compl. Ch3 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL) RW
36 2’compl. sign
2’compl. Ch3 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
37 2’compl. sign 2’compl. Ch4 temper.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
38 2’compl. sign 2’compl. Ch4 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
39 2’compl. sign
2’compl. Ch4 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL) RW
40 2’compl. sign
2’compl. Ch4 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
41 2’compl. sign 2’compl. Ch5 temper.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
42 2’compl. sign 2’compl. Ch5 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
43 2’compl. sign
2’compl. Ch5 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL) RW
44 2’compl. sign
2’compl. Ch5 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
45 2’compl. sign 2’compl. Ch6 temperature
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
46 2’compl. sign 2’compl. Ch6 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
47 2’compl. sign
2’compl. Ch6 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL) RW
48 2’compl. sign
2’compl. Ch6 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
49 2’compl. sign 2’compl. Ch7 temper.
1°C ÷ 240°C
1°C÷200°C (*)
R
50 2’compl. sign 2’compl. Ch7 max temperat.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
51 2’compl. sign
2’compl. Ch7 temper.
alarm set point
0°C ÷ 240°C
0°C÷200°C (*)
As (AL) RW
52 2’compl. sign
2’compl. Ch7 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
53 2’compl. sign 2’compl. Ch8 temper.
1°C ÷ 240°C
1°C÷200°C (*)
R
54 2’compl. sign 2’compl. Ch8 max temperat.
–10°C ÷ 240°C
–48°C ÷200°C (*)
R
55 2’compl. sign
2’compl. Ch8 temper.
alarm set point
0°C ÷ 240°C
0°C÷200°C (*)
As (AL) RW
56 2’compl. sign
2’compl. Ch8 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As
(TRP)
RW
(*) for version –40°C ÷ +200°C
