40
10
327
LOCK
ACTUAL
M3
M
Yd
MODE: SLOPE
PIN SEEKER
+
A) THE DISTANCE SHOWN IN THE LARGE
FONT SIZE WILL BE THE FULL DISTANCE.
C) THE DISTANCE SHOWN, LOWER
LEFT CORNER, IS THE UP/DOWN
(+/-) SLOPE CORRECTED DISTANCE.
D) THE DISTANCE SHOWN, LOWER
RIGHT CORNER, IS THE CALCU-
LATED ACTUAL DISTANCE.
A) FULL DISTANCE
B) ANGLE
C) SLOPE UP/DOWNHILL
INDICATOR (+/-)
D) SLOPE CORRECTED
ACTUAL DISTANCE
32Y
40Y
-10
D
E
C
B
A
D
-
MAINTENANCE
1. REMOVE DUST OR DIRT ON THE LENS SURFACE USING A SOFT, OIL
FREE CLOTH BEFORE STORING THE RANGEFINDER.
2. REMOVE SMUDGES OR FINGERPRINTS BY GENTLY RUBBING WITH A
SOFT GLASS CLEANING CLOTH OR A HIGH-QUALITY, OIL-FREE TISSUE.
3. IF WATER VAPOR ENTERS THE UNIT PLACE IT IN DIRECT SUNLIGHT
FOR TWO TO THREE HOURS. DO NOT TURN ON.
4. USE LENS CLEANERS DESIGNED FOR USE WITH PHOTOGRAPHIC
EQUIPMENT OR ISOPROPYL ALCOHOL TO WIPE THE LENSES.
ALWAYS APPLY CLEANING FLUID TO THE CLEANING CLOTH FIRST.
DO NOT POUR ANY LIQUIDS ONTO THE LENS
5. WHEN STORING THE RANGEFINDER FOR PERIODS LONGER THAN
30 DAYS, REMOVE THE BATTERY FIRST TO AVOID CORROSION.
6. ALWAYS STORE THE RANGEFINDER AT ROOM TEMPERATURE OR IN A
CONTROLLED AND DRY AREA WITH LOW HUMIDITY. NEVER KEEP IN
A VERY HOT NOR VERY COLD ATMOSPHERE.
D
