SLOPE + FOCUS
TURN ON - SLIDE BUTTON RIGHT (EXPOSE YELLOW INDICATOR)
SLOPE
FOCUS
TURN OFF - SLIDE BUTTON LEFT (NO YELLOW - TOURNAMENT MODE)
1. LOOK THROUGH THE
RUBBER EYEPIECE
2. TURN THE EYEPIECE/DIOPTER TO THE
LEFT OR RIGHT UNTIL THE IMAGE IS CLEAR
A. PIN SEEKER INDICATOR
B. DISTANCE (METERS / YARDS)
C. MODE NUMBER
D. BATTERY JUICE
E. AIMING CROSS-HAIRS
F. ANGLE INDICATOR
G. UPHILL / DOWNHILL INDICATOR
H. SLOPE - CORRECTED DISTANCE
LCD DISPLAY
FEATURES
1000
00
1000000
8
LOCK
SCAN
ACTUAL
M
M
Yd
THE KLYR RANGEFINDER USES EYE-SAFE BEAMS TO MEASURE DISTANCE
TO OBJECTS UP TO 800 YARDS AWAY, BY MEASURING THE TIME IT TAKES
FOR THE LASER PULSE TO REFLECT OFF OF THE TARGET AND RETURN.
RANGEFINDER WILL NOT MEASURE DISTANCES WHILE AIMING THROUGH
GLASS OR PLASTICS (IE. WINDOWS AND GOLF CART WIND SHIELDS)
INDEX
A
B
C
D
H
F
E
G
