G ADJUSTING AIR FLOW DIRECTION
• Adjust the air flow direction properly otherwise, it might cause discomfort
or cause uneven room temperatures.
• Adjust the horizontal louver using button on the remote controller.
• Adjust the vertical louver manually.
Adjusting the vertical Air Flow Direction (up - down)
The air conditioner automatically adjusts the vertical air flow direction in accor-
dance with the operating mode.
To set the vertical air flow direction
Perform this function while the unit is in operation. Keep pressing the AIR DIRECTI-
ON button on the remote controller to move the louver to the desired direction.
• Adjust the vertical air flow direction to the desired direction.
• In subsequent operations, the vertical air flow is automatically set in the
direction to which you adjusted the louver by pressing the AIR DIRECTION
button.
To set the horizontal air flow direction (left - right)
Adjust the horizontal louver manually using the lever on the left or right side of
the horizontal louver arm (depending on model). When the air conditioner is in
operation and the horizontal louver is in a specific position, move the lever at left
(or right, depending on model) end of the air outlet to the desired position.
To automatically swing the air flow direction (up - down)
Perform this function while the air conditioner is in operation.
• Press the SWING button on the remote controller.
• To stop the function, press the SWING button again. Press AIR DIRECTION button to lock louver in
desired position.
G
NOTE!
All the pictures in this manual and on the gift box are for explanation and indication purpose
only. They may be slightly different from the air conditioner you purchased. The actual shape
shall prevail.
CAUTION!
Take care, do not touch the fan behind the vertical louvers!
Lever
fig. 8
