M TECHNICAL DATA
* EN 14511-2007
** To be used as indication
*** Moisture removal at 32°C, 80% RH
Model TS 226 TSCS 226 TSCS 232
Type air-conditioner Wall mounted split
Cooling capacity nominal* W 2600 3200
EE Class* A
EER* 3.22 3.22 3.23
Heating capacity nominal* W 2800 2800 3200
Heating performance A
COP* 3.63 3.60
Dehumidifying capacity L / 24 h 24 24 26
Power consumption cooling kW 0.81 0.81 0.99
Power consumption heating kW 0.77 0.77 0.89
Annual energy consumption * kWh 405 405 495
Power supply V / Hz / Ph 230~ / 50 / 1
Current (nom.) A 3.7/3.5
3.7/3.7 4.6
Max. Current A 5.5
5.5 7.0
Air flow ** m3/h 480/380/330
480/380/330 580/500/400
For rooms up to** m3 65-90
65-90 80-100
Compressor type Rotary
Fan speeds 3
Thermostatic range ºC 17 - 30
Operating range ºC -5 - +43
Controls manual / mechanic / electronic Electronic remote
Remote control Yes / No Y
Air filter type(s) Screen, Active carbon
Refrigerant type / charge K / g R410A / 620
R410A / 730 R410A / 790
Refrigerant pipe diameter Liquid - Gas mm 6,35/9,53
Quick Connector Quick Connector
Normal pressure suction / discharge
(excessive)
bar 8 / 26 (15 / 42)
Dimensions indoor unit (w x h x d) mm 790x275x190
Dimensions outdoor unit (w x h x d) mm 700x535x235
700x535x235 780x540x250
Net weight indoor unit kg 9
13 14
Net weight outdoor unit kg 25
25 26
Gross weight indoor unit kg 11
16 17
Gross weight outdoor unit kg 27
29 28
Sound pressure level indoor unit dB(A) 34/37/40
34/37/40 35/38/41
Sound pressure level outdoor unit dB(A) 53 53 54
Unit protection indoor IP IP20
Unit protection outdoor IP IP24
Fuse rating T3.15A / 250V
4
130
