Tecumseh TM049XA Basic Troubleshooting And Service Information

24
TRANSAXLES
Model
No.
Quantity
301 Non-Serviceable
600 24 oz./710 ml Oil
800 30 oz./887 ml Grease
801 36 oz./1065 ml Grease
820 36 oz./1065 ml Grease
900 26 oz./769 ml Grease
910 18 oz./532 ml Grease
915 10 oz./296 ml Grease
920 30 oz./887 ml Grease
930 30 oz./887 ml Grease
1200 48 oz./1420 ml Oil ††
1301
1305
1309
1313
32 oz./946 ml Oil
1302
1303
1304
1306
1307
1308
1310
131
1
1312
1314
1315
1316
1317
1318
1319
1320
1321
1322
1325
1328
1329
44 oz./1301 ml Oil
1323
1326
1327
24 oz./710 ml Oil
MST200 16 oz./473 ml Oil
VST205
and
1800's
2300
††††
64 oz./1892 ml Oil
2400 32 oz./946 ml Oil
Tecumseh and Peerless
®
Lubrication Requirements
Grease: Bentonite Grease
Part Number 788067C
Oil: SAE E.P. 80W90 Oil
Part Number 730229B
† Refer to O.E.M. Technician’s Manual for type of lubricant.
†† To be filled through shift lever opening.
††† Some 1000 Right Angle and T-Drives use Bentonite Grease.
†††† Tecumseh's current policy on VST and 1800 Series transaxles
with internal failure, is to replace the complete unit. VST and 1800's
have two separate reservoirs which can be checked for diagnostic
purpose only. The output gear reservoir can be checked with a small
pocket rule as outlined in the Tecumseh & Peerless Transmission and
Drive Products Handbook.
Refer to Tecumseh & Peerless Transmission and Drive Products
Handbook, 691218.
NOTE
Use ONL
Y the recommended lubricant in all models as listed to insure proper operation and long life.
TRANSMISSION
Model
No.
Quantity
2500 †
2600 †
700
700H
12 oz./355 ml Grease
12 oz./355 ml Grease
2800 †
HYDROSTATIC
TRANSAXLES and
TRANSMISSIONS
1800 Series
Limited service; use
Kit Part No. 799030
VST205/705
Limited service; use
Kit Part No. 799030
L
TH 2000
Limited service;
final drive ONL
Y
8 oz./240 ml Oil
2100 Non-Serviceable
LDP-10 Non-Serviceable
RIGHT ANGLE
AND T-DRIVES
Model
No.
Quantity
All Models
Except *
4 oz./1
18 ml Grease
*1408-P91
*1409-P91
*1410-P91
*3002
*3003
*3028
*3029
*3035
3 oz./89 ml Grease
1000 Series
6 oz./180 ml Oil
†††
1
100 16 oz./473 ml Oil
DIFFERENTIALS
All Models 3 oz./89 ml Grease
TWO SPEED AXLE
All Models 2 oz./59 ml Grease
THREE SPEED AXLE
All Models 2 oz./59 ml Grease
