Section IV– Operating Instructions
2. Sensor calibration tables now appear on 1830A.
Figure 4.16 - Loaded Sensor Data
Normal Shutdown Procedure
Press the power button will start the normal shut down procedure. Shutdown will take several
seconds to insure proper shutdown has occurred. Do not unplug the 1830A until the LCD goes
black and fan stop indicating shutdown is com
200
205
210
215
220
225
230
235
240
245
250
0
2
4
6
8
10
12
14
16
1830A Heater Regulation Chart
RF Power (mW)
Heater Voltage (V)
Rail Voltage
Check Voltage
Heater Current (mA)
mW
Regulating
Voltage
Heating
Voltage
Heater Rail
Voltage
