Tegam 1830A - Specifications

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com
1-2
Section I – Introduction
Specifications
(Includes performance characteristics, description, power and utility information
and environmental information)
Power Range (typical, sensor dependent)
0.001 to 30 mW (-30 to +14 dBm)
Frequency Range
100 kHz to 110 GHz (sensor
dependent)
Accuracy
±0.05% of reading, ±0.5 μW
(0.1% at 1 mW)
Measurement Scale
mW dB
Cal Factor Resolution
4 digits, linear decimal
Bridge Resistance
Variable from 50 Ω to 300 Ω (RF
termination 12.5 Ω to 75 Ω)
Connectors
Bias Voltage
Temp
14-pin Quick Connect
4-pin mini-microphone
Heater Controller
8 VDC @ 200 mA (compatible with
all TEGAM and Weinschel
thermistor mounts)
Environmental Specified Temperature Range
Operating Temperature
Storage Temperature
Calibration Temperature
Humidity
+17°C to +29°C (+63°F to +84°F)
1
0 °C to +55 °C (+32 °F to +131 °F)
-40 °C to +75 °C (-40 °F to +167 °F)
+17°C to +29°C (+63°F to +84°F)
0% to 95%, non-condensing
Power Requirements
100 to 240 Vac, 48 to 62 Hz, 75
VA max
Input Power Fuse
250 V, 1.5 Amp (slow blow)
Weight
2 kg (4.4 lb)
Physical Dimensions
Height
Width
Depth
8.89 cm (3.5 in)
21.59 cm (8.5 in)
36.5 cm (14.5 in)
Table 1.1 Physical and Electrical Specifications
1
Please note that the Celsius scale specifications are controlling, the Fahrenheit conversions are
approximations for information only.
