Teka Airtech P10 - 11. Technical data

11. Technical data
Supply voltage
V
400
Frequency
Hz
50
Type of current
Ph
3
Engine power
kW
11,0
Air flow volume max.
m³/h
9000
Negative pressure max.
Pa
4500
Protection class
IP54
ISO class
F
Welding fume extraction class
(according to EN ISO 15012-1)
W3
Width (without / with intake ducts)
Depth
Height
mm
mm
mm
800 / 4900
1200
4000
Weight (without / with intake ducts)
kg
ca. 700 / 900
Sound pressure level
(measured according to DIN 45635-1)
dB(A)
ca. 72
Allowed ambient temperature
°C
+5 to +35
Allowed max. humidity
%
70
Compressed air supply
dry / oil-free
Necessary external pressure
bar
see chapter “Connecting the compressed air
supply”
BA_Airtech_P10_IFA_190319_EN
23
19.03.2019
