1x left , 1x right . It is mounted at the upper and lower toggle levers ("G"). For this 2 screws
M6x12 per toggle lever briefly have to be solved, then screw again including the mounting
brackets.
Fig.: dust collector housing Fig.: connecting the housings
Fig.: filter housing
