BA_ECO-Cube_190815_EN.docx 24 15.08.2019
11 Technical data
Filter device
ECO-Cube
Engine power
kW
5,5 7,5 11
Air volume flow (possible operating point)
m³/h (cfm)
3800 (2237) 4200 (2472) 8140 (4792)
Under pressure (possible operating point)
Pa (psi)
3250 (0,47) 3800 (0,55) 2700 (0,39)
Mains voltage
V 400 / 480
400
Frequency
Hz 50 / 60
50
Type of current
Ph
3
Protection type
IP 54
ISO class
F
Control voltage
V
24 V DC
Duty cycle
%
100
Width x Depth x Height (housing dimen-
sions)
mm (in) 800 x 800 x 3200 (31,5 x 31,5 x 126)
Weight
kg (lb) ca. 490 (ca. 1078)
Filter insert
4 filter cartridges
Filtration area of the filter system
m² (ft²)
100 (1080)
Dust filtration class
(according to DIN EN 60335-2-69:2008)
M
Cleaning art
Compress burst
Sound pressure level
dB/A
75
external pressure
bar (psi)
5 to 10 (72,5 to 145)
Compressed air supply
Dry / oil free
Ambient temperature
°C (°F)
+5 to +35 (+41 to +95)
Max. air moisture
%
70
