Teka HS-615 - Oven Components and Control Panel; HS-615;HS-610 Oven Diagram; Control Panel Overview

6
HS-615/HS-610
1 Control Panel
2 Oven Seal
3 Grill Element
4 Tray Support
5 Grid
6 Tray
7 Hinge
8 Door
9 Air Outlet
10 Fixing to Unit
11 Grill Screen
12 Smoke Outlet
13 Light
14 Back Wall Panel
15 Fan
Control Panel
1 Minute timing switch.
2 Function selector.
3 Temperature selector.
4 Heating indicator light. Indicates that the
heat is going to the food and it goes out
when the set temperature is reached.
1
2
3
5
6
7
8
4
10
9
11
12
13
14
15
Model HS-615/HS-610
Model HS-605
42 1 3
42 1 3
