Description of the oven
1
Control panel
2
Door lock (only for
pyrolytic models)
3
Grill element
4
Tray supports
5
Grid shelf
6
Tray
7
Hinge
8
Inner Glass
9
Air cooling outlet
10
Unit mounting
11
Lamp
12
Back Wall Panel
13
Fan
14
Oven Seal
15
Door
1
10
12
13
14
15
5
6
8
3
2
4
9
11
7
Control panel
1
Function control dial
2
Electric clock/timer
3
Temperature control dial
1
Function control dial
2
Electric clock/timer / Selected temperature
3
Temperature control dial
1 2 3
HSC Models
min
MAX
1 2 3
HBC P / HSC P Pyrolytic models
