Tekmar tekmarNet 4 Setpoint Control 161 Wiring Brochure

9 of 12 © 2008 W 161 - 12/08
Troubleshooting the Wiring
General
The following tests are to be performed using standard testing practices and procedures
and should only be carried out by properly trained and experienced persons.
A good quality electrical test meter, capable of reading from at least 0 - 300 V (ac),
0 - 2,000,000 Ohms, and testing for continuity is essential to properly test the wiring
and sensors.
tN4 C R Com S1
12345
###
7
R1
6
Rh
