118-0417-011 14
7. Once the face of the Grinding Wheel
coupler is flat on the rubber face of
the VERSATURN™ Coupler, rotate
the VERSATURN™ Coupler's Lock
Ring clockwise until the "Locked" tab
(6) is facing upward, to lock the
grinder onto the lathe.
8. Double check the Lock ring is
tightened snug and that the Grinding
Wheel Accessory is not lose.
OPERATION INSTRUCTIONS:
Ensure the “ON/OFF” switch is in the “OFF” position before plugging the power cord into
the AC power source. Ensure there are no tools or work pieces in contact with the grinding
wheels when the grinder is turned “ON.” Failure to observe these procedures could result in
damage to the VERSATURN™ Grinding Wheel, tools, work pieces, or serious personal injury
to the operator or bystanders. Limit speed to max 3000rpm and always start machine at zero
(0)
DO NOT attempt to “grind” work pieces made of WOOD or MAGNESIUM. Using wood
with the VERSATURN™ Grinding Wheel could easily start a fire or cause severe irreversible
damage to the work piece. Grinding work pieces made of magnesium or magnesium alloys can
ignite causing sudden very intense fires. Magnesium fires cannot be easily extinguished.
ABSOLUTELY DO NOT THROW WATER ON A MAGNESIUM FIRE. USE ONLY A FIRE
EXTINGUISHER RATED FOR SUCH FIRES. When water is introduced to a magnesium fire,
the sudden temperature change could cause the metal to explode sending very hot pieces
throughout the work area possibly igniting other fires.
Ensure the tool rests are securely tightened and the eye shields are in place and
properly tightened.
Allow the VERSATURN™ Grinding Wheel to run for at least one minute to warm up
the grinding wheel. NEVER place a work piece against a “COLD” grinding wheel.
Place the work piece on the tool rest and apply even pressure as contact is made with
the abrasive stone.
When sharpening tools, start on one end of the tool and slide its surface across the
grinding stone in a firm even speed and pressure. Reverse the direction for the other
side.
