Version 2024 25
<Interface Settings>
This is to switch between metric and imperial units of measurement.
This is to choose between standard and precision mode.
This is to choose options for the inch unit fraction display.
This is to choose from a list how the machine should behave when the set
drilling depth is reached.
This is where the height sensor can be calibrated.
This is to choose different display options.
This is to switch between different sound settings.
This is to change the display language of the pillar drill.
<Motor Performance>
This is to toggle the maximum speed of the pillar drill between 3000 and 5500 rpm
(default: 3000 rpm).
This is to set the power output to <HIGH>, <MEDIUM> or <LOW>.
This is to turn the braking function on or off. The braking function provides power
to the motor even after the <OFF> or emergency stop button has been pressed.
This helps stop the spindle more quickly and reduce the free spinning time.
Attention!
Do not press any buttons or try to use the user interface when
the motor has the braking engaged. This function is turned off
by default.
This is to toggle between different settings of the load sensor:
• <Jam recognition>: This function detects whether the drill bit has become
jammed and shuts off the motor. (Default: ON)
• <Spike Detect>: This function detects if the load on the motor spikes
abnormally and shuts off the motor. (Default: ON)
• <Spike Threshold.>: This is to determine the load threshold which constitutes
a load spike in percent.
This is to set the vibration sensor sensitivity. The vibration sensor automatically
detects vibrations of the pillar drill and shuts off the machine when the safety
threshold is reached (e.g. if a workpiece has been caught or is spinning around).
You can choose between the following four settings:
• <OFF> (default)
• <LOW>
• <MEDIUM>
• <HIGH>
