SuperNova
2
Chuck Maintanence
This guide covers all steps, beginning from when your chuck is on the lathe; you may wish to skip
several steps in order to advance to where you are currently at.
Tools needed: 1½” spanner
Circlip pliers (and safety glasses)
3mm Allan key (provided with Supernova 2 chuck)
Plastic hammer (or block of wood)
Also you will need multi purpose grease for re-greasing chuck when re-assembling
Removing The Supernova
2
from the Insert and Wood lathe
The Supernova 2 chuck on a Nova 3000 DVR lathe
Removing grub screw to release insert
Using the 3mm Allan key provided with the Supernova, release the M6 grub screw (turning in an
anti-clock wise direction to loosen)
Using 11/2" Spanner to remover chuck from lathe
