Teknic Amazon IPC-3 - Mounting Hole Dimensions; DIN Rail Adapter

Mounting Hole Dimensions
DIN Rail Adapter (optional, available from third-party)
60.5
14.15
9.23
36.0
11.0
160.0
[6.3]
[1.417]
39.7
[1.563]
36.7
[1.445]
[2.382]
[.433]
[.557]
[.363]
80.0
[3.15]
MOUNT
THIS END UP
MOUNT
THIS END UP
B
B
A
A
A
Dia. 2.50mm [.098”]
Qty. 3, M3 x 0.5 - 6H
Max. penetration into
case = 5.5mm
A
B
Dia. 3.45mm [.136”]
Qty.3, 8-32 UNC-2B
Max. penetration into
case = 0.25 in.
B
*
A size holes for use with Phoenix UTA-89
DIN Rail Adapter. (item not sold by Teknic)
NOTE: The IPC casting includes holes for mounting the Phoenix Contact UTA-89
DIN rail adapter. If you use this DIN rail adapter, and the DIN rail itself is screwed
to a solid wall or cabinet, you will have to install standoffs as shown below to
provide sufficient clearance for mounting.
Phoenix PN UTA-89
(also PN 2853970)
DIN Rail Adapter
Use three mounting screws and
standoffs in indicated positions.
For DIN Rail Clip *
For Direct Mount
Tolerances
+/- .015 in.
+/- .381 mm
Tol. 2 =
+/- .008 in.
+/- .203 mm
Tol. 1 =
Tol. 1
Tol. 1
Tol. 1
Tol. 2
Tol. 2
Tol. 2
Tol. 2
Tol. 1
Tol. 1
mm
[inches]
Units
Standoffs, unthreaded (qty. 3)
Metric: Length 10mm, inner diameter >3mm
English: Length 3/8”, inner diameter >3mm
Screws for use with standoffs (qty. 3)
Metric: M3 x 0.5, Class 6H, length: 16-18mm
4
