Teknion BM_R - Installation Step #4: Wall Panel Installation; Installation Step #5.1: Component Attachment; Installation Step #5.2: Component Attachment

E04-50100
1/4-20 x 5/8"
E07-0077
#10 x 7/8"
IF APPLICABLE
Install Wall Panel. To install Wall
Panel, refer to L04-64041.
SI APPLICABLE
Installer le Panneau Mural avant de
continuer. Pour installer le Panneau
Mural, se référer au guide L04-64041.
#4
CLICK!
#5.1
#5.2
Expansion Casegoods Installation Guide / Guide d'installation
2021-01-19 14:27
BM_R, BH_WB, BH_CB, BH_PT, BH_MT, BH_EP, BH_LB, BH_L, BH_LT, BH_RB, BH_PP & BHK__ -
Height-Adjustable Table & Kneespace - Mid-Height / Table ajustable en hauteur & Module - Mi-Hauteur
4 / 9
L04-64040_R01
2046
For additional information on this installation contact Technical Support. Pour plus d'informations sur cette installation contactez le support technique.
40BH_
Tighten set
screws
Serrer les
vis pression
