Teknion Leverage - Top Trim Installation Process

STEP 2: Mount the Screen onto one of the Slots in Table Rail as illustrated.STEP 1: Assemble Nut and Bolt arrangement as illustrated.
NOTE: Make sure the orientation of T-Nut is correct.
Section:
Description:
Page No:
Date:
ASSEMBLE NUT AND BOLT ARRANGEMENT MOUNT THE SCREEN
TLE_406
2 of 3
May 2020
OVERHEAD UPMOUNT INSTALLATION
MOUNTED STORAGE AND ACCESSORIES
leverage Installation Guides
B
B
C
A
B
C
C
B
