Teknion Leverage - Intermediate End Trim Installation

1/16''
1/16''
Section:
Description:
Page No:
Date:
PANEL ADD-ON SCREEN INSTALLATION (CONTINUED)
Sept 2021
6 of 8
TLE_558
PANEL ADD-ON SCREEN
PANELS
leverage Installation Guides
NOTE: Please leave a 1/16" gap between Metal Sub-Assembly when installing multiple Panel Frames with Extended.
Front View
Top View
NOTE: Please leave a 1/16" gap between Metal Sub-Assembly
when installing multiple Panel Frames with Extended.
