Tekno EB48 2.2 - Page 22

TKR1346
TKR1228
TKR1228
Step
N-5
Step
N-6
Step
N-7
Step
N-4
TKR1402
TKR1523
TKR9024
TKR9011
TKR1402
TKR1346
TKR1402
TKR1344
TKR9026
TKR1402
M3x8mm Button Head Screw
x10
TKR9019
TKR9026
TKR1344
TKR1402
TKR1344
M4x12mm Flat Head Screw
x4
TKR1346
M4x15mm Flat Head Screw
x2
TKR1228
M4 Countersunk Washer
X2
Note: Motor, Pinion Gear,
& Set Screw for Pinion
Gear
(not included)
TKR1523
M3x10mm Cap Head Screw
x2
For 36mm all condition,
and 42mm onroad.
Bag N
Battery Tray/Mud Guard
22
(4 cell)
(50-100 ft Straight)
Small Track Medium Track
(100-150 ft Straight)
Large Track
(150-200 ft Straight)
15 - 16 tooth
14 - 15 tooth
16 - 17 tooth
15 - 16 tooth
17 - 18 tooth
16 - 17 tooth
1900-2050kv
2050-2200kv
Motor
