10
Warnings & Cautions
The P3 has built in troubleshooting/diagnostic features.
Situation: screen flashes Warning! Open Ground
Probable Cause: Trailer is connected and P3 loses
connection to battery ground.
Situation: screen flashes Warning! Overload
Probable Cause: P3 detects an excessive current
overload condition during operation.
Situation: screen flashes Warning! Output Shorted
Probable Cause:
1. Detects brake output wire shorted to ground
short during idle condition.
2. Use of some test lights or non-Tekonsha testers
can cause this problem.
Situation: screen flashes Caution! Power Loss
Probable Cause: Power to P3 interrupted during
braking or stop lamp active while connecting power
to TBC.
Situation: screen flashes No Trailer Connection!
Probable Cause:
1. Trailer not connected to tow vehicle.
2. Trailer connected with open circuit on
brake line.
3. Trailer connector disconnected or corroded.
4. Loss trailer brake magnet ground.
ALTERNATING SCREENS
