TEKTELIC Communications Kona Macro Gateway User Manual

Kona Macro User Guide T0005158_UG Version 0.6
TEKTELIC Communications Inc. Confidential Page 9 of 32
3G/4G Modem
SIM card
SIM card
Industry standard, located behind SIM card access
port cover
Copper Ethernet
Port
Threaded, circular, RJ-45
Shenzhen Chogori Technology Co., Ltd. approved
mating connector (p/n 33000111-02 or equivalent)
Direct DC Power
Input Port
Threaded, circular, 2
contact DC power
Shenzhen Chogori Technology Co., Ltd. approved
mating connector (p/n 23002211-02, or equivalent)
Earth Ground
Chassis Protective Earth
Ground terminal
Industry standard 2-hole lug, 1/4 x 0.75” spacing
1.3 Specifications
The Kona Macro Gateway specifications are listed in Table 3.
Table 3: Kona Macro Gateway Specifications
Attribute
Specification
Dimensions
222.2mm (8.7”) wide x 101mm (4.0”) deep x 287.3mm (11.3”) tall
Weight
5.1 kg (11.3 lbs)
Operating Temperature
-40°C to 60°C (-40°F to 140°F) at sea level Including solar loading.
Relative Humidity
10% to 100%
Operating Altitude
-60 m to 4,000 m (-197 ft to 13,123 ft)
Power Input, Direct DC
48 VDC nominal, 37 to 57 VDC operating range.
Positive or negative ground referenced feed. SELV source required.
5A recommended input overcurrent protection (2A minimum to 10A
maximum allowed).
Power Input, PoE
802.3 at (Type 2 Class 4), Mode A or Mode B or 4-pair Mode.
Power Consumption
20 W maximum
Weather Tightness
UL Type 6 (IP-67)
Regulatory Compliance
CSA/UL 60950-1 & CSA/UL 60950-22, CE IEC 60950-1
FCC Pt. 15, RSS-247, EN 301 489-1
FCC Pt. 27 (North American 2 Variant Only)
Surge Protection
All interfaces are protected to primary levels.
