492/492P Service Vol. I (SN B030000 & up)
TABLE OF CONTENTS (cont)
Page
Section 5 THEORY OF OPERATION (cont)
110 MHz IF Amplifier and 3rd
Converter
.......................................
5-20
110 MHz IF Amplifier
..................
5-20
110 MHz Bandpass Filter
..........
5-21
3rd Converter.................................. 5-22
IF Section
.......................................
5-23
Variable Resolution Section
........
5-23
Logarithmic Amplifier and
Detector...................................... 5-29
Display Section................................ 5-31
Functional Description
................
5-31
Video Amplifier............................ 5-33
Video Processor
........................ 5-35
Digital Storage............................ 5-38
Vertical Section
...................... 5-39
Horizontal Section
..................
5-43
Deflection Amplifiers
..................
5-45
Z-Axis Circuits
............................ 5-46
High Voltage Supply
..................
5-47
Crt Readout................................ 5-48
Frequency Control Section
..............
5-55
Sweep........................................ 5-55
Span Attenuator
........................
5-58
1 st Local Oscillator Driver
..........
5-61
Preselector Driver
...................... 5-63
Sweep Shaper and Bias Circuits. 5-66
Center Frequency Control
..........
5-67
Phaselock System (Option 03)
........
5-70
Functional Description
................
5-70
Phaselock Control
......................
5-71
Error Amplifier and Synthesizer.. 5-73
Controlled Oscillator, Offset
Mixer, and Strobe Driver
............
5-76
Digital Control.................................. 5-77
Processor.................................... 5-78
Memory Board
............................ 5-87
Front Panel................................ 5-88
Accessories Interface Board .... 5-94
Main Power Supply and Fan Driver. 5-94
Page
Section 5 THEORY OF OPERATION (cont)
Main Power Supply.................... 5-94
492P GENERAL PURPOSE
INTERFACE BUS
...................... 5-98
Section 6 RACKMOUNT/BENCHTOP VERSIONS
Introduction
.....................................
6-1
Electrical Characteristics
................
6-1
Standard Accessories.......................... 6-3
Optional Accessories............................ 6-3
Rackmounting Installation Dimensions. 6-3
Slide-Out Tracks.................................. 6-3
Mounting Procedure
........................ 6-4
Alternate Rear Mounting Methods. . 6-5
Slide-out Track Lubrication
..............
6 - 6
Removing or Installing the
492/492P Spectrum Analyzer from
or in the Rackmount Cabinet
..........
6 -6
Removing the Side, Top, and
Bottom Panels................................ 6-7
Installing Semi-rigid Coaxial
Cables to Access the Cabinet
Rear Panel Connectors to the
Front Panel of the Instrument
(Option 31)...................................... 6-7
PREPARING THE INSTRUMENT FOR
CALIBRATION OR MAINTENANCE. . . 6-9
Appendix A GLOSSARY
General Terms...................................... A-1
Terms Related to Frequency
................
A-2
Terms Related to Amplitude
................
A-2
Terms Related to Digital Storage for
Spectrum Analyzers............................ A-3
CHANGE INFORMATION
iv
REV AUG 1981
