AFG1000 Series Quick Start User Manual
17
Default settings Default settings
Menu/System Default setting
Output configuration (Start Phase only available in AFG1062)
Function Sine
Frequency 1.000 000 000 kHz
Start phase 0°
Amplitude 1.000 V
p-p
Offset 0 mV
Symmetry (Ramp) 50.00%
Duty (Pulse) 50.00%
Output units V
p-p
Output impedance 50 Ω
Sweep
Sweep start frequency 100.000 Hz
Sweep stop frequency
1.000 kHz
Sweep time
1 s
Sweep type Linear
Sweep source Internal
Modulation (PWM, ASK, and PSK only available in AFG1062)
Modulation waveform 100.000 Hz, Sine (except FSK)
100.000 Hz, Square (FSK)
AM depth 100%
FM deviation 100.000 Hz
PM deviation 0°
PWM deviation 0.0%
FSK hop frequency 100.000 Hz
FSK rate 100.000 Hz
ASK rate 100.000 Hz
PSK rate 100.000 Hz
Burst
Burst mode N Cycle
Burst count 1
Trigger source Internal
Trigger interval 1 s
System related settings
Clock reference Internal
The Default bezel button in the Utility menu does not reset the Language option.
