Tektronix AFG1000 Series

Operating basics
AFG1000 Series Quick Start User Manual
35
Sweep a waveform
The Sweep outputs a waveform with the output signal frequency varying linearly or
logarithmically.
Start frequency
Stop frequency
Sweep time
Center frequency
Frequency span
To set sweep parameters, do the following:
1. Select a waveform
among sine, square,
or ramp, and then
push the front-panel
Mod button.
2. Press Sweep to enter
sweep menu.
